產品規格：

Frequency Response (–10dB)

35Hz – 40kHz

Frequency Response (–3dB)

46Hz – 38kHz

Power Handling (Continuous/Peak)

100W/400W

Maximum Recommended Amplifier Power

200W

靈敏度 (2.83V/1m)

90dB

Crossover Frequencies

400Hz; 6dB/octave; 2.5kHz; 8kHz; 24dB/octave

Nominal Impedance

6 Ohms

高音單體

2" (50mm) Pure-titanium compression driver; Bi-Radial horn

低音單體

Dual 8" (200mm) with cast-aluminum frames

UHF Transducer

3/4" (19mm) Polyester-film ring radiator; neodymium magnet; EOS waveguide

尺寸 (H x W x D)mm

(1104mm x 259mm 418mm)

重量

35.6kg
